Item |
PartNo |
Description |
Qty |
Options |
Ref |
Alt |
|
? |
EH7195 |
O-RING (1) |
1 |
|
|
|
|
? |
EJ7475 |
GEAR, SPEED SENSOR |
1 |
|
|
|
|
? |
58F-32-00202 |
SPINDLE |
1 |
|
|
|
|
? |
PC3059 |
BEARING ASSEMBLY, INNER (1) |
1 |
|
|
|
|
? |
562-22-32290 |
PIN (1) |
2 |
|
|
|
|
? |
ED3772 |
SPACER, BEARING |
1 |
|
|
|
|
? |
EH7194 |
O-RING (1) |
1 |
|
|
|
|
? |
EH7196 |
O-RING (1) |
1 |
|
|
|
|
? |
ED3775 |
ADAPTER, BRAKE |
1 |
|
|
|
|
? |
58F-32-50010 |
FRONT BRAKE ASSEMBLY (SEE INDEX) |
1 |
|
65352 |
|
|
? |
569-33-81241 |
ADAPTER |
1 |
|
|
|
|
? |
58C-32-00452 |
TANK, CATCHMENT |
1 |
|
|
|
|
? |
07002-52034 |
O-RING (1) |
1 |
|
|
|
|
? |
PC0651 |
SEAL ASSEMBLY (2) |
1 |
|
|
|
|
? |
PC1431 |
SEAL, OIL (1)/(2) |
1 |
|
|
|
|
? |
58F-32-40030 |
CARRIER, SEAL |
1 |
|
|
|
|
? |
58F-32-40051 |
BRACKET, MOUNTING |
6 |
|
|
|
|
? |
58F-32-00151 |
CARRIER, FLOATING SEAL |
1 |
|
|
|
|
? |
58F-32-00170 |
SEAL ASSEMBLY (1) |
1 |
|
|
|
|
? |
58F-32-00161 |
CARRIER, FLOATING SEAL |
1 |
|
|
|
|
? |
WA4780 |
PLUG, O-RING |
2 |
|
|
|
|
? |
58F-22-00850 |
VENT, BREATHER (1) |
2 |
|
|
|
|
? |
58F-32-00180 |
O-RING (1) |
1 |
|
|
|
|
? |
07000-52018 |
O-RING (1) |
1 |
|
|
|
|
? |
EH7193 |
O-RING (1) |
1 |
|
|
|
|
? |
D2930 |
CAPSCREW, SOCKET HEAD - 1/2" - 13NC X 3/4" |
6 |
|
|
|
|
? |
C1612 |
CAPSCREW - 1/2" - 13NC X 1" |
12 |
|
|
|
|
? |
C1613 |
CAPSCREW - 1/2" - 13NC X 1 1/4" |
4 |
|
|
|
|
? |
DF6928 |
CAPSCREW - 1/2" - 13NC X 1 3/4" |
16 |
|
|
|
|
? |
WA0360 |
FLAT WASHER, HARDENED - 1/2" |
28 |
|
|
|
|
? |
WA5669 |
CAPSCREW, 12 PT - 1 1/4" - 12NF X 3 1/2" |
57 |
|
|
|
|
? |
WB1231 |
CAPSCREW - 1 1/4" - 12NF X 8" |
32 |
|
|
|
|
? |
58B-09-50080 |
FLAT WASHER, HARDENED - 1 1/4" |
75 |
|
|
|
|
? |
58F-SM-AK060 |
NOTE: (1) INCLUDED IN 58F-SM-AK060 SPINDLE |
|
|
|
|
|
? |
|
MAINTENANCE KIT. BALANCE OF PARTS ON PREVIOUS FIGURE. |
|
|
|
|
|
? |
58F-BK-AK070 |
(2) INCLUDED IN 58F-BK-AK070 FRONT BRAKE |
|
|
|
|
|
? |
|
SEAL KIT. |
|
|
|
|
|
? |
|
(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
|
|
|
|
