Item |
PartNo |
Description |
Qty |
Options |
Ref |
Alt |
|
? |
58F-32-00290 |
PISTON AND HOUSING ASSEMBLY (1) |
1 |
|
|
|
|
? |
58F-32-00280 |
• HOUSING, PISTON |
1 |
|
|
|
|
? |
58F-33-40000 |
• SEAL (3) |
1 |
|
|
|
|
? |
58F-33-40010 |
• SEAL (3) |
1 |
|
|
|
|
? |
EG4953 |
• PISTON |
1 |
|
|
|
|
? |
PB8864 |
• SPRING |
12 |
|
|
|
|
? |
ED3327 |
• GUIDE, SPRING |
12 |
|
|
|
|
? |
VL1222 |
• CAPSCREW - 1/2" - 13NC X 5" |
12 |
|
|
|
|
? |
VM0315 |
PLUG |
3 |
|
|
|
|
? |
WA1589 |
CAPSCREW, 12 PT - 7/8" - 9NC X 3" |
102 |
|
|
|
|
? |
WA5659 |
FLAT WASHER, HARDENED |
102 |
|
|
|
|
? |
VM0317 |
PLUG |
1 |
|
|
|
|
? |
58F-32-00270 |
GEAR, RING |
1 |
|
|
|
|
? |
EH7197 |
O-RING (3) |
2 |
|
|
|
|
? |
ED3343 |
GEAR, INNER |
1 |
|
|
|
|
? |
EM8367 |
DAMPER (2) |
2 |
|
|
|
|
? |
EM8365 |
DISC, SEPARATOR (2) |
9 |
|
|
|
|
? |
EM8366 |
DISC, FRICTION (2) |
10 |
|
|
|
|
? |
58F-32-50021 |
PLATE, BACK |
1 |
|
|
|
|
? |
C1611 |
CAPSCREW - 1/2" - 13NC X 3/4" (3) |
8 |
|
|
|
|
? |
C1540 |
LOCKWASHER - 1/2" (3) |
16 |
|
|
|
|
? |
WA2704 |
COVER, FLANGE HEAD (3) |
2 |
|
|
|
|
? |
WA3574 |
O-RING |
2 |
|
|
|
|
? |
PC1427 |
DOWEL, SPRING |
2 |
|
|
|
|
? |
|
NOTE: (1) NOT SERVICED AS AN ASSEMBLY. |
|
|
|
|
|
? |
XK1161 |
(2) INCLUDED IN XK1161 BRAKE DISC KIT. |
|
|
|
|
|
? |
58F-BK-AK070 |
(3) INCLUDED IN 58F-BK-AK070 FRONT BRAKE |
|
|
|
|
|
? |
|
SEAL KIT. |
|
|
|
|
