Корень Dump Trucks Komatsu AFE42-Q 630E S/N 32418 LEIGHTON(afe42-q)
FAN CLUTCH INSTL (ED5412)(064 : 35416)
Title Page Reference
VARIABLE SPEED FAN CLUTCH (AK1940) 066 15243



































Item PartNo Description Qty Options Ref Alt
? HA1510 • HOSE 1
? VH0596 • • ELBOW - 90 DEG 3
? VM9910 • • LOCKWASHER - #8 2
? TF6248 • • FLAT WASHER - #8 2
? DC2726 • • MACHINE SCREW #8UNC X 3/8" 2
? HA1286 • • HOSE 1
? PB8299 • • VALVE, SOLENOID 1
? SV7053 • • ADAPTOR, STRAIGHT 1
? C1604 • • CAPSCREW - 3/8" - 16NC X 1 1/2" 2
? C0312 • • LOCKWASHER - 3/8" 2
? TZ3234 • • PLATE, MOUNTING 1
? VW7014 • • HOSE 1
? • • (NOT USED THIS APPLICATION) 65535
? VN9149 • • CAPSCREW - 1/2" - 13NC X 4 1/2" 6
? C1540 • • LOCKWASHER - 1/2" 6
? EB4175 • • SPACER 1
? AK1940 • • CLUTCH, FAN (SEE INDEX) 1
? VL7692 • • CAPSCREW - 5/8" - 11NC X 2" 4
? WA0361 • • FLAT WASHER - 5/8" 4
? C1541 • • LOCKWASHER - 5/8" 4
? PB8321 • • SENSOR, THERMAL 1
? R2510 • • NIPPLE, CLOSE 1
? R0086 • • BUSHING, PIPE 1
? S7170 • • FITTING, PIPE 1
? TG2960 • • CLAMP 3
? VN1705 • • FITTING, TEE 1
? WA4823 • • FITTING 1
? HA0990 • • HOSE 1
? TF3035 • • FITTING, TUBE 1
? HA1454 • • HOSE 1
? VM3923 • • FITTING, TUBE 1
? WA4884 • • FITTING, TUBE 1
? TF6283 • • ADAPTOR 1
? TF4633 • • ELBOW - 90 DEG 1
