Item	PartNo	Description	Qty
?	VE3706	• END, CAP	1
?	VE3705	• • FAN MOUNTING HUB	1
?	VE3696	• • RETTAINER, SEAL ASSM (FRONT) (1)	1
?	VE4331	• • WEAR SLEEVE (FRONT) (1)/(2)	1
?	VE3685	• • MAIN BEARING (FRONT) (1)	1
?	VE1304	• • FACING PLATE	7
?	VE3690	• • CLUTCH HUB	1
?	VE4418	• • SNAP RING, EXTERNAL (1)	1
?	VE3692	• • BEARING, SLEEVE (REAR) (1)	1
?	VE3692	• • BEARING, SLEEVE (FRONT) (1)	1
?	VE3680	• • OIL SEAL (FRONT) (1)/(2)	1
?	VE3694	• • BEARING RETAINER (FRONT)	1
?	VE3700	• • O-RING SEAL (1)/(2)	1
?	VE3683	• • BOLT	8
?	VE3684	• • LOCKWASHER	8
?	VE1305	• • CLUTCH PLATE, STEEL	7
?	VE3687	• • PISTON	1
?	VE3688	• • SEAL RING (1)/(2)	1
?	VE6849	• • PULLEY	1
?	VE3684	• • LOCKWASHER	8
?	VE3683	• • BOLT	8
?	VE3700	• • O-RING SEAL (1)/(2)	1
?	VE3710	• • BEARING RETAINER (REAR)	1
?	VE3680	• • OIL SEAL (REAR) (1)/(2)	1
?	VE3697	• • SNAP RING, INTERNAL (1)	1
?	VE3689	• • SEAL RING, (SMALL) (1)/(2)	1
?	VE3701	• • SPRING WASHER (1)/(2)	1
?	VE3697	• • SNAP RING, INTERNAL (1)	1
?	VE3702	• • SNAP RING, EXTERNAL (1)	1
?	VE3703	• • SHIM (1)/(2)	1
?	VE3708	• • SHAFT & BRACKET ASSM	1
?	TH5103	• • SEAL RING (1)/(2)	2
?	VE3711	• • PITOT TUBE (1)/(2)	2
?	VE3679	• • SLEEVE, WEAR (REAR) (1)/(2)	1
?	VS7793	• • FITTING, ORIFICE	1
?	VE3696	• • RETAINER, SEAL ASSM (REAR) (1)	1
?	VE3685	• • MAIN BEARING (REAR) (1)	1
?	VE3686	• • SNAP RING, EXTERNAL (1)	1
?	VS7811	• • NAME PLATE KIT (1)/(2)	1
?	VE3714	• • ENGINE INTERCOOLER THERMO SENSOR (120 - 130 DEG)	1
?	VE3715	• • ENGINE JACKET COOLANT THERMO SENSOR (180 - 190 DEG)	1
?	VE3742	• • NOTE: (1) INCLUDED IN VE3742 OVERHAUL KIT.	65535
?	VE3741	• • (2) INCLUDED IN VE3741 SEAL KIT.	65535
