Корень Dump Trucks Komatsu AFE77-C 830E-5 S/N A50006, A50017, A50025 CLIFFS NORTHSHORE(AFE77-C)
REAR AXLE SERVICE CENTER - LH(714 : 68454)




































Item PartNo Description Qty Options Ref Alt
? A6485 BUSHING 1
? WB0466 FITTING, STRAIGHT 4
? 58E-60-02340 HOSE 1
? MM0203 LOCKWASHER - M3 2
? EM4776 PLATE, FILL 1
? 58E-60-02330 HOSE 1
? WB0474 FITTING, STRAIGHT 1
? DH3095 FITTING, PIPE 1
? PC2362 GAUGE, LEVEL 1
? XB7946 BRACKET 1
? MM0604 CAPSCREW - M10 X 1.50 X 20 3
? MM0471 LOCKWASHER - M10 3
? MM0461 FLAT WASHER - M10 3
? D1423 PLUG, PIPE 1
? PC2375 COUPLING, TEST 1
? S7182 FITTING, ELBOW 1
? XB7947 PLATE 1
? VC5162 CAPSCREW - 5/8" - 11NC X 1 1/4" 1
? TR9082 FLAT WASHER - 5/8" 1
? EM4789 CAP 1
? MM0340 SCREW - M4 X 0.7 X 8 2
? PC2378 LANYARD 1
? EM4783 PLATE 1
? WB0300 FITTING, ELBOW - 45 DEG 1
? R8796 NIPPLE 1
? PB2306 VALVE, SHUTOFF 1
? WB0274 FITTING, ELBOW - 90 DEG 1
? SG6077 NIPPLE 1
? PC2376 VALVE, SHUTOFF 1
? WB0255 FITTING, ELBOW - 90 DEG 1
? 58E-60-02300 HOSE 1
? S5823 BUSHING 1
? WB0284 FITTING, ELBOW - 45 DEG 1
? 58E-60-02310 HOSE 1
? PC2740 ADAPTER 2
? MM0327 SCREW - M3 X 0.5 X 8 2
