Item	PartNo	Description	Qty
?	58F-80-06030	BOX, FUEL	1
?	MM0618	CAPSCREW - M12 X 1.75 X 30	3
?	MM0472	LOCKWASHER - M12	3
?	MM0462	FLAT WASHER - M12	3
?	WB0479	FITTING, STRAIGHT	1
?	58F-80-05920	NIPPLE	1
?	MM0583	CAPSCREW - M6 X 1.00 X 25	3
?	MM0469	LOCKWASHER - M6	3
?	MM0459	FLAT WASHER - M6	3
?	58B-06-20020	BRACKET	2
?	EK9883	SPACER	1
?	MM0461	FLAT WASHER - M10	1
?	MM0471	LOCKWASHER - M10	1
?	MM0178	NUT - M10 X 1.50	1
?	58E-02-11160	FITTING, STRAIGHT	1
?	PC3115	LATCH, ADJUSTABLE	1
?	TF6246	SCREW - #8 - 32NC X 5/8"	3
?	TF6248	FLAT WASHER - #8	3
?	VM9910	LOCKWASHER - #8	3
?	TV2179	NUT - #8 - 32NC	3
?	SR6528	SCREW - #12 - 24NC X 3/4"	3
?	DF3445	FLAT WASHER - #12	3
?	VD2047	LOCKWASHER - #12	3
?	TR8580	NUT - #12 - 24NC	3
?	PB2154	RECEIVER	1
?	PB2020	CAP	1
?	MM0593	CAPSCREW - M8 X 1.25 X 20	2
?	MM0460	FLAT WASHER - M8	2
?	58B-02-00650	RECEIVER, FAST FILL	1
?	58E-02-03240	• CAP, FAST FILL RECEIVER	1
?	DC4087	GROMMET, RUBBER	1
?	58F-93-00320	PLATE, DIESEL SULFER	2
?	58F-93-00410	PLATE, DECAL	2
?	09632-61480	PLATE, SAFETY	2
