Корень Dump Trucks Komatsu AFE77-C 830E-5 S/N A50006, A50017, A50025 CLIFFS NORTHSHORE(AFE77-C)
FRONT BRAKE JUNCTION VALVE PIPING 2/2(392 : 64627)

















Item PartNo Description Qty Options Ref Alt
? WB0501 FITTING, ELBOW - 90 DEG 2
? HA8642 HOSE 2
? WB0538 FITTING, ELBOW - 45 DEG 1
? WB0533 FITTING, ELBOW - 45 DEG 2
? VW8099 HOSE 1
? WB0252 FITTING, ELBOW - 90 DEG 1
? HA0434 HOSE 1
? WB0499 FITTING, ELBOW - 90 DEG 1
? WB1300 CLAMP, CUSHIONED - 5/8" 8
? TR4436 FLAT WASHER, HARDENED - 3/8" 4
? TC1231 LOCKWASHER - 3/8" 4
? TC1233 NUT - 3/8" - 16NC 4
? WB3098 CLAMP, CUSHIONED - 3/8" 1
? WB3093 CLAMP, CUSHIONED - 1" 1
? MM0461 FLAT WASHER - M10 1
? MM0471 LOCKWASHER - M10 1
? MM0178 NUT - M10 X 1.50 1
