Корень Dump Trucks Komatsu AFE77-C 830E-5 S/N A50006, A50017, A50025 CLIFFS NORTHSHORE(AFE77-C)
CONTROL BOX 5/7(294 : 45661)













































Item PartNo Description Qty Options Ref Alt
? 58F-43-01140 DUCT, FLEXIBLE EXHAUST 1
? 58F-43-01050 CLAMP, HOSE 2
? 58F-43-01040 DUCT, FLEXIBLE EXHAUST 1
? GE0148 PANEL ASSEMBLY 1
? VJ6586 CAPSCREW - #10 - 32NF X 3/4" 1
? VE4601 LOCKWASHER - #10 1
? VE4655 FLAT WASHER - #10 1
? VE4902 NUT - 1/4" - 20NC 2
? XA5003 LOCKWASHER - 1/4" 2
? XA4233 FLAT WASHER - 1/4" 2
? GE0860 RESISTOR ASSEMBLY 2
? 58F-43-01840 BOOT, HOLZ RUBBER 1
? 58F-43-01250 PLATE, MOUNTING 1
? VE4699 LOCKWASHER - 1/2" 4
? VE4698 NUT - 1/2" - 13NC 4
? VE4519 FLAT WASHER - 1/2" 4
? 58F-43-01440 CAPSCREW - 1/2" - 13NC X 11 3/4" 2
? 58F-43-01540 STUD 2
? 58F-43-01450 RESISTOR 4
? VE7202 WASHER, NARROW - 1/4" 1
? VE1959 BUSHING 2
? 58F-43-01930 ROD 2
? 58F-43-01640 BRACKET 2
? XA3129 CAP, LENS 1
? XA3130 ADAPTER 1
? PB3606 SPACER 1
? 58B-43-00250 WASHER - 1/2" OD 1
? GE0177 BOARD, PRINTED WIRE 1
? VE4602 NUT - #10 - 32NF 2
? 58F-43-01420 INSULATION 1
? VE4687 LOCKWASHER - 3/8" 3
? VE4700 NUT - 3/8" - 16NC 3
? VE4515 FLAT WASHER - 3/8" 3
? 58F-43-01950 GASKET 2
? 58F-43-01630 CAPACITOR, DC POWER 2
? 58F-43-01430 WASHER - 1 3/7" 1
? 58F-43-01550 SPACER 1
? 58B-43-01200 RESISTOR BOARD 2
? XA3593 SUPPORT 1
? NOTE: NS = NOT SHOWN
? XA3143 STUD 4
? 58F-43-01860 HARNESS, WIRING - LV2 1
? 58F-43-01870 HARNESS, WIRING - CMH 1
? 58F-43-01960 HARNESS, WIRING - LV3 1
? 58F-43-01970 HARNESS, WIRING - CGH 7
