Корень Dump Trucks Komatsu AFE NEW AFE77-BQ 830E-5 S/N A50198 - A50199, A50203 - A50204 KAL / STOCK(afe77-bq)
HEAT EXCHANGER PB9796(C-026 : 61656)












Item PartNo Description Qty Options Ref Alt
? BF2668 TUBE, CONNECTION 2
? BF2670 BRACKET, MOUNTING 2
? BF2665 PLUG 4
? BF2662 TUBE, COPPER 1
? BF2663 BONNET 2
? BF2664 GASKET 2
? VE7367 NUT - 1/2" - 13NC 32
? VE7366 LOCKWASHER - 1/2" 32
? BF2671 CAPSCREW - 1/2" - 13NC X 2 1/2" 12
? BF2666 CAPSCREW - 1/2" - 13NC X 2 1/4" 20
? NOTE: NS = NOT SHOWN
? VM0314 PLUG 2
