Корень Dump Trucks Komatsu AFE NEW AFE77-BP 830E-5 S/N A50187, A50192 - A50193 KAL / STOCK(afe77-bp)
LOW TEMPERATURE CORE 58E-03-03010(C-010 : 69956)
















Item PartNo Description Qty Options Ref Alt
? 58E-03-03200 TANK 1
? 58E-03-03210 TANK, CENTER 1
? 58E-03-03220 TANK 1
? 58E-03-03230 MEMBER, SIDE 1
? 58E-03-03240 MEMBER, SIDE 1
? 58E-03-03250 ROD, TENSION TIE 1
? 58E-03-03260 AIR BAFFLE, TOP 1
? 58E-03-03270 AIR BAFFLE, BOTTOM 1
? XA2721 SEAL, RUBBER 816
? XA2720 SEAL, RUBBER 816
? 58E-03-03280 TUBE, M-FIN 816
? C1540 LOCKWASHER - 1/2" 28
? VE3460 CAPSCREW, HEAVY DUTY - 1/2" - 13NC X 1" 20
? C1614 CAPSCREW - 1/2" - 13NC X 1 1/2" 8
? XA5351 RIVET 2
? 58F-03-02460 TAG, DATA GENERAL 1
