Item |
PartNo |
Description |
Qty |
Options |
Ref |
Alt |
|
? |
PC3385 |
GAUGE PANEL (SEE FIG 61325) |
1 |
|
61325 |
|
|
? |
PB8658 |
CAPSCREW - M6 X 1.00 X 30 |
10 |
|
|
|
|
? |
EK7947 |
LOUVER, RECTANGULAR |
2 |
|
|
|
|
? |
58E-54-04790 |
DASH MODULE, UPPER RH (SEE FIG 43488) |
1 |
|
43488 |
|
|
? |
58F-54-00602 |
DASH MODULE, LOWER RH (SEE FIG 43747) |
1 |
|
43747 |
|
|
? |
WB3295 |
DECAL, SHIFT SELECTOR |
1 |
|
|
|
|
? |
WB2490 |
DECAL, KEY SWITCH WARNING |
1 |
|
|
|
|
? |
DC9822 |
DRIVE SCREW |
8 |
|
|
|
|
? |
SM2648 |
PLATE, SEAL RETAINER - RH |
1 |
|
|
|
|
? |
SM2646 |
PLATE, SEAL RETAINER - LH |
1 |
|
|
|
|
? |
PB9829 |
CAPSCREW - M6 X 1.00 X 16 |
10 |
|
|
|
|
? |
TX7829 |
SEAL, STEERING COLUMN |
1 |
|
|
|
|
? |
58E-54-08490 |
DASH MODULE, LOWER LH (SEE FIG 48503) |
1 |
|
48503 |
|
|
? |
EK8962 |
SEAL, LOWER MODULE |
2 |
|
|
|
|
? |
EK8961 |
SEAL, UPPER MODULE |
2 |
|
|
|
|
? |
PC3588 |
PANEL, STATUS LIGHT |
1 |
|
|
|
|
? |
SM2466 |
SCREW - #10 - 24NC X 1" |
4 |
|
|
|
|
? |
EL5675 |
DASH PANEL, MOLDED |
1 |
|
|
|
|
? |
SM5145 |
TUBE (1) |
2 |
|
|
|
|
? |
WA4513 |
SCREW - #10 - 24NC X 1/2" (1) |
4 |
|
|
|
|
? |
EK7946 |
ADAPTER, HOSE |
2 |
|
|
|
|
? |
CC6103 |
CLAMP, WORM DRIVE |
4 |
|
|
|
|
? |
SM2783 |
HOSE, AIR |
2 |
|
|
|
|
? |
SM4435 |
PLATE, BENT-FILLER (1) |
1 |
|
|
|
|
? |
|
NOTE: NS = NOT SHOWN |
|
|
|
|
|
? |
PC1938 |
HARNESS, WIRING - MAIN GAUGE PANEL |
1 |
|
|
|
|
? |
PC1939 |
HARNESS, WIRING - STATUS LIGHT PANEL |
1 |
|
|
|
|
? |
|
NOTE: (1) NOT INCLUDED IN THE INSTRUMENT PANEL ASSM. |
|
|
|
|
