Корень Dump Trucks Komatsu AFE NEW AFE59-HV 930E-4 S/N GAE2285 - UP TECK - GLIDER KIT(afe59-hv)
OVERHEAD DASH MODULE(G-048 : 48540)
Title Page Reference
AIR CLEANER RESTRICTION GAUGE MODULE G-054 56160


















Item PartNo Description Qty Options Ref Alt
? RADIO MODULE 1
? EM0646 PLATE, BLANK 1
? XC2701 PLATE, MOUNTING 1
? 58E-54-18410 DASH, OVERHEAD 1
? EK2766 PLATE 1
? 58E-54-18700 SHEET 1
? PB8658 CAPSCREW - M6 X 1.00 X 30 12
? SM2682 SCREW, COUNTERSUNK 3
? PC0724 SPEAKER ASSEMBLY 2
? EM0177 HARNESS, WIRING - SPEAKER 2
? WA3367 NUT ASSEMBLY - #10 - 32NC 8
? MM0176 NUT - M6 X 1.00 14
? MM0207 LOCKWASHER - M6 14
? 58B-54-02000 TRIM, EDGE 2
? 31127R1 CAPSCREW - M6 X 1.00 X 12 6
? NOTE: NS = NOT SHOWN
? EL0296 HARNESS, WIRING - SPEAKER 2
