Корень Dump Trucks Komatsu AFE NEW AFE59-HV 930E-4 S/N GAE2285 - UP TECK - GLIDER KIT(afe59-hv)
CAB VINYL 1/2(G-008 : 43768)
















Item PartNo Description Qty Options Ref Alt
? 58F-54-07710 SHEET, VINYL 1
? 58F-54-07920 BLOCK, RH 1
? 58F-54-00900 SHEET, VINYL 1
? 58F-54-00870 SHEET, VINYL 1
? 58F-54-01060 SHEET, VINYL 1
? 58F-54-00910 SHEET, VINYL 1
? 58F-54-07910 BLOCK, LH 1
? 58F-54-00830 SHEET, VINYL 1
? 58F-54-07720 SHEET, VINYL 1
? 58F-54-00820 SHEET, VINYL 1
? 58F-54-00810 SHEET, VINYL 1
? 58F-54-07900 SHEET, VINYL 1
? 58F-54-00800 SHEET, VINYL 1
? 58F-54-00840 SHEET, VINYL 1
? NOTE: NS = NOT SHOWN
? SM2325 ADHESIVE, SPRAY
