Корень Dump Trucks Komatsu AFE NEW AFE59-HV 930E-4 S/N GAE2285 - UP TECK - GLIDER KIT(afe59-hv)
CAB INSULATION(G-006 : 43767)
































Item PartNo Description Qty Options Ref Alt
? SM5991 INSULATION 1
? SM5989 INSULATION 1
? XC1546 INSULATION 1
? XC1545 INSULATION 1
? SM6012 INSULATION 1
? SM6013 INSULATION 1
? SM6014 INSULATION 1
? SM6015 INSULATION 1
? SM5996 INSULATION 1
? SM5997 INSULATION 2
? EK2820 INSULATION 1
? SM5984 INSULATION 1
? 58E-54-30350 RETAINER, HEADLINER 2
? PB8658 CAPSCREW - M6 X 1.00 X 30 14
? 58F-54-01120 HEADLINER 1
? SM0547 INSULATION 2
? SM0546 INSULATION 2
? 58F-54-01980 COVER, LH 1
? SM2963 INSULATION 2
? SM2304 INSULATION 2
? SM5994 INSULATION 1
? EK2819 INSULATION 1
? EK2821 INSULATION 1
? SM5995 INSULATION 1
? SM5993 INSULATION 1
? SM0543 INSULATION 1
? 58F-54-01990 COVER, RH 1
? 58E-09-00061 SCREW, TAP - 1/4" - 14NC X 1 1/4" 14
? 58E-09-00070 FLAT WASHER - 1/4" 14
? 58E-54-50150 SPACER 14
? NOTE: NS = NOT SHOWN
? SM2226 FOAM HARNESS RETAINER 2
