Корень Dump Trucks Komatsu AFE NEW AFE59-HV 930E-4 S/N GAE2285 - UP TECK - GLIDER KIT(afe59-hv)
CAB MOUNTING(G-002 : 42707)









Item PartNo Description Qty Options Ref Alt
? CAB ASSEMBLY (1) 1
? SM2052 • PLATE, LIFTING 4
? VN9057 • CAPSCREW - 1/2" - 13NC X 1 3/4" 12
? TR5445 • LOCKWASHER - 1/2" 12
? MM0074 CAPSCREW - M24 X 3.00 X 70 32
? 01643-32460 FLAT WASHER - M24 32
? EL1949 SHIM, FRONT - 1MM
? EL1950 SHIM, REAR - 1MM
? NOTE: (1) ORDER FROM FACTORY.
