Item	PartNo	Description	Qty
?	58F-22-00900	AXLE HOUSING ASSEMBLY	1
?	TX8110	• SLEEVE (2)	4
?	WB1162	CAPSCREW, 12 PT - 1 1/4"-7NC X 3"	28
?	WA4735	FLAT WASHER - 1 1/4"	28
?	58F-22-40020	PIVOT EYE ASSEMBLY (3)	1
?	58F-22-40010	• EYE, PIVOT (1)	1
?	PC1291	• BEARING, SPHERICAL (1)	1
?	WB1154	• CAPSCREW, 12 PT - 3/4" - 10NC X 6" (1)	14
?	VL2993	• LOCKNUT - 3/4" - 10NC (1)	14
?	EL0047	• RETAINER, BEARING (1)	2
?	ED4952	SLEEVE (1)	1
?	EK0867	PIN, PIVOT (1)	1
?	VN9952	LOCKNUT - 5/8" - 11NC (2)	2
?	EG3028	SPACER (1)	2
?	EK0866	PLATE, LOCKING (1)	1
?	WB1059	CAPSCREW, 12 PT - 1 1/4" - 7NC X 4 1/2" (1)	5
?	WA4729	FLAT WASHER, HARDENED - 5/8" (2)	4
?	58B-09-01650	CAPSCREW - 5/8" - 11NC X 2 1/2" (1)	3
?	VC1390	LOCKWASHER - 5/8" (1)	3
?	EM8109	SHOULDER BOLT - 5/8" - 11NC X 7.16" (2)	1
?	EM8110	SHOULDER BOLT - 5/8" - 11NC X 6.73" (2)	1
?	58F-50-00130	SPACER (2)	4
?	EH7812	ANTI-SWAY BAR W/BEARINGS	1
?	EH7813	• BAR, ANTI-SWAY	1
?	VN9351	• RING, RETAINING (2)	4
?	PB0027	• BEARING, SPHERICAL (2)	2
?	EH7811	PIN, PANHARD ROD (2)	2
?	58F-MP-AK110	NOTE: (1) INCLUDED IN 58F-MP-AK110 NOSE CONE PIN KIT.
?	58F-MP-AK060	(2) INCLUDED IN 58F-MP-AK060 ANTI-SWAY BAR KIT.
?		(3) NOT SERVICED AS AN ASSEMBLY. ORDER
?		INDIVIDUAL COMPONENT PARTS.
