Корень Dump Trucks Komatsu AFE NEW AFE59-HV 930E-4 S/N GAE2285 - UP TECK - GLIDER KIT(afe59-hv)
LH VERTICAL LADDER & HANDRAILS(A-040 : 47148)
























Item PartNo Description Qty Options Ref Alt
? XB2935 STEP, GRILLE 2
? MM0619 CAPSCREW - M12 X 1.75 X 35 3
? MM0714 FLAT WASHER, HARDENED - M12 44
? MM0472 LOCKWASHER - M12 32
? MM0179 NUT - M12 X 1.75 22
? XB2826 HANDRAIL 1
? 58B-54-50600 HANDRAIL 1
? 58B-54-50610 HANDRAIL 1
? MM0620 CAPSCREW - M12 X 1.75 X 40 18
? 58F-54-20360 GATE, LH 1
? MM0623 CAPSCREW - M12 X 1.75 X 60 4
? MM0617 CAPSCREW - M12 X 1.75 X 25 4
? 58F-54-30000 PLATE, BENT 1
? 58F-54-05460 PLATE, BENT 1
? PC2325 SPRING, RH 1
? 58F-54-05470 SPACER 1
? MM0613 CAPSCREW - M10 X 1.50 X 80 1
? MM0471 LOCKWASHER - M10 1
? MM0461 FLAT WASHER - M10 2
? MM0178 NUT - M10 X 1.50 1
? 58F-54-05520 HINGE 2
? 58F-54-30070 BLOCK, SPACER 2
? MM0462 FLAT WASHER - M12 10
? MM0621 CAPSCREW - M12 X 1.75 X 45 3
