Корень Dump Trucks Komatsu AFE NEW AFE59-HV 930E-4 S/N GAE2285 - UP TECK - GLIDER KIT(afe59-hv)
RH DECK HANDRAILS(A-030 : 46257)


























Item PartNo Description Qty Options Ref Alt
? 58F-54-01771 HANDRAIL, RETARDING GRID - REAR 1
? 58F-54-01822 HANDRAIL, RETARDING GRID - FRONT 1
? 58F-54-20291 HANDRAIL, RH DECK 1
? 58F-54-20270 HANDRAIL, RH DECK 1
? MM0618 CAPSCREW - M12 X 1.75 X 30 22
? MM0472 LOCKWASHER - M12 44
? MM0714 FLAT WASHER, HARDENED - M12 62
? MM0179 NUT - M12 X 1.75 23
? MM0619 CAPSCREW - M12 X 1.75 X 35 20
? EL9093 BRACKET 4
? C1616 CAPSCREW - 1/2" - 13NC X 2" 24
? TR5445 LOCKWASHER - 1/2" 24
? TR6008 FLAT WASHER - 1/2" 24
? 58E-54-13870 BRACKET 2
? EM2229 PAD 4
? 58E-54-13860 PAD 2
? 58F-54-03920 BRACKET 6
? MM0620 CAPSCREW - M12 X 1.75 X 40 3
? 58F-54-40820 TUBE 1
? 58B-54-50350 TUBE 1
? MM0461 FLAT WASHER - M10 1
? MM0471 LOCKWASHER - M10 1
? WB3097 CLAMP, CUSHIONED - 1/2" 1
? MM0178 NUT - M10 X 1.50 1
? 58F-54-03900 PLATE, BENT 1
? 58F-54-03910 PLATE, BENT 1
