Корень Dump Trucks Komatsu AFE NEW AFE59-HV 930E-4 S/N GAE2285 - UP TECK - GLIDER KIT(afe59-hv)
RH DECK & RETARDING GRID INSTALLATION(A-024 : 62356)



















Item PartNo Description Qty Options Ref Alt
? 58F-54-00103 DECK, RH 1
? EJ2443 BRACKET 1
? EC7589 PLATE 1
? MM0031 CAPSCREW - M20 X 2.50 X 45 4
? MM0707 FLAT WASHER, HARDENED - M20 4
? D104556 BUMPER 1
? VN9780 FLAT WASHER - 9/16" 1
? VG7811 LOCKNUT - 1/2" - 13NC 1
? EC7594 FLAT WASHER, HARDENED - 3/8" 16
? MM0697 LOCKNUT - M20 X 2.50 8
? MM0091 CAPSCREW - M20 X 2.50 X 80 5
? MM0085 CAPSCREW - M20 X 2.50 X 70 3
? MM0168 CAPSCREW - M20 X 2.50 X 180 8
? 01643-32060 FLAT WASHER, HARDENED - M20 16
? MM0475 LOCKWASHER - M20 8
? MM0182 NUT - M20 X 2.50 8
? EM9043 SHIM 8
? EM9046 SHIM 16
? RETARDING GRID ASSEMBLY 1
