Title	Page	Reference
WIPER LINKAGE ASSEMBLY PB9926	G-108	42777

Item	PartNo	Description	Qty	Ref
?	PB9923	MOTOR, WIPER - 24 VOLT	1
?	MM0592	CAPSCREW - M8 X 1.25 X 16	5
?	MM0712	FLAT WASHER, HARDENED - M8	14
?	MM0470	LOCKWASHER - M8	5
?	SM4345	PLATE	1
?	MM0581	CAPSCREW - M6 X 1.00 X 16	3
?	MM0711	FLAT WASHER, HARDENED - M6	3
?	MM0469	LOCKWASHER - M6	3
?	PB9926	WIPER LINKAGE ASSEMBLY (SEE INDEX)	1	42777
?	PC1823	ARM, WET WIPER	2
?	EM8722	TUBE, HEAT SHRINK	1
?	PB9925	BLADE, WIPER	2
?	MM0022	CAPSCREW - M8 X 1.25 X 20	4
?	MM0460	FLAT WASHER - M8	4
?	EG0735	TEE, HOSE	1
?	TF6380	GROMMET, RUBBER	2
?	SM4477	HOSE	2
?	EG3904	HOSE	1
?		NUT - M8 X 1.25 (1)	1
?		COVER (1)	1
?		NUT - M20 X 1.00 (1)	1
?		WASHER (1)	1
?		WASHER (1)	1
?	EM8721	TUBE, HEAT SHRINK	1
?		NOTE: NS = NOT SHOWN
?	XA3071	NOTE: (1) NOT SERVICED SEPARATELY. ORDER XA3071
?		HARDWARE KIT.

?
