Item	PartNo	Description	Qty
?	EK8720	CONDENSER (1)	1
?	TG5720	CAPSCREW - 3/8" - 16NC X 1" (1)	8
?	WA4726	FLAT WASHER, HARDENED - 3/8"	26
?	TG9225	LOCKNUT - 3/8" - 16NC (1)	8
?	HA7675	HOSE (1)	1
?	WA1732	O-RING	1
?	VC8762	CAPSCREW - 3/8" - 16NC X 1 1/2" (1)	2
?	TC1231	LOCKWASHER - 3/8" (1)	4
?	TC1233	NUT - 3/8" - 16NC (1)	4
?	WB3922	CLAMP, CUSHIONED - 11/16" (1)	12
?	HA7993	HOSE	1
?	WA1731	O-RING (1)	1
?	WB1304	CLAMP, CUSHIONED - 9/16" (1)	11
?	C1605	CAPSCREW - 3/8" - 16NC X 1 3/4" (1)	1
?	MM0471	LOCKWASHER - M10 (1)	6
?	MM0461	FLAT WASHER - M10 (1)	8
?	TC1234	CAPSCREW - 3/8" - 16NC X 3/4" (1)	4
?	HE5611	LOCKNUT - 3/8" - 16NC (1)	2
?	TR4436	FLAT WASHER, HARDENED - 3/8" (1)	1
?	MM0178	NUT - M10 X 1.50 (1)	6
?	DA0557	WASHER (1)	8
?	VY9850	MOUNT, RUBBER (1)	4
?	C1616	CAPSCREW - 1/2" - 13NC X 2" (1)	4
?	EK8761	MOUNT, CONDENSER (1)	1
?	892124C1	SPACER (1)	1
?	58E-09-00010	BRACKET (1)	1
?	MM0605	CAPSCREW - M10 X 1.50 X 25 (1)	2
?	WB3098	CLAMP, CUSHIONED - 3/8" (1)	1
?	WB1302	CLAMP, CUSHIONED - 5/16" (1)	1
?	58F-PM-AK040	NOTE: (1) INCLUDED IN 58F-PM-AK040 POWER MODULE KIT.
