Корень Dump Trucks Komatsu AFE NEW AFE75-AL 980E-5 S/N A50141 ESPERANZA SUR(afe75-al)
AUTOMATIC LUBRICATION SYSTEM PIPING - FRONT 3/4(W-006 : 64981)
Title Page Reference
INJECTOR VS1947 W-010 68822





















Item PartNo Description Qty Options Ref Alt
? MM0461 FLAT WASHER - M10 13
? MM0610 CAPSCREW - M10 X 1.50 X 50 4
? TA4410 INJECTOR ASSEMBLY, 3-PIECE 2
? VS1947 • INJECTOR (SEE INDEX) 3 68822
? 58E-60-20720 • ADAPTER, BOLT (1) 3
? 58E-60-20710 • MANIFOLD, THREE INJECTOR 1
? WB0462 FITTING, STRAIGHT 1
? VW7990 CAP, PROTECTIVE 6
? 58B-60-02630 HOSE 1
? WB0252 FITTING, ELBOW - 90 DEG 4
? VW8099 HOSE 2
? SV7053 FITTING, STRAIGHT 4
? 58B-60-00180 HOSE 2
? 58B-60-00190 HOSE 2
? 58B-60-02610 HOSE 1
? WB0289 FITTING, ELBOW - 45 DEG 3
? WB0384 FITTING, TEE 1
? 58F-60-50580 HOSE 1
? C5770 PLUG, PIPE - 3/8" 1
? NOTE: (1) TORQUE TO 45-50 FT-LBS.
