Item |
PartNo |
Description |
Qty |
Options |
Ref |
Alt |
|
? |
58E-06-00390 |
DUCT, WIRING |
3 |
|
|
|
|
? |
58E-06-00410 |
COVER, DUCT |
3 |
|
|
|
|
? |
58E-06-10350 |
NUT, RIBBED - #10 - 24NC |
14 |
|
|
|
|
? |
58E-06-10360 |
SCREW, FLANGE - #10 - 24NC X 3/4" |
14 |
|
|
|
|
? |
58E-06-11371 |
TAG, PLATE |
1 |
|
|
|
|
? |
58E-06-30050 |
BUS BAR |
3 |
|
|
|
|
? |
58E-06-30060 |
COVER, BUS BAR |
1 |
|
|
|
|
? |
58E-06-30070 |
BUS BAR |
1 |
|
|
|
|
? |
58E-06-00430 |
COVER, WIRING |
1 |
|
|
|
|
? |
MM0459 |
FLAT WASHER - M6 |
2 |
|
|
|
|
? |
MM0587 |
CAPSCREW - M6 X 1.00 X 45 |
2 |
|
|
|
|
? |
PC2644 |
TIMER, 2 HOUR DELAY |
2 |
|
|
|
|
? |
58B-06-50320 |
NAME PLATE - 24VDC |
1 |
|
|
|
|
? |
58B-06-50340 |
NAME PLATE - GB31 |
1 |
|
|
|
|
? |
WB3104 |
FLAT WASHER - M5 |
12 |
|
|
|
|
? |
58B-06-50370 |
NAME PLATE - EMT |
1 |
|
|
|
|
? |
58E-06-04150 |
RELAY - 24V, 75 AMP |
9 |
|
|
|
|
? |
58B-06-50350 |
NAME PLATE - KEY SWITCH POWER RELAY |
1 |
|
|
|
|
? |
58B-06-50360 |
NAME PLATE - 12V POWER RELAY |
1 |
|
|
|
|
? |
58B-06-50390 |
NAME PLATE - HORN RELAY |
1 |
|
|
|
|
? |
58B-06-50400 |
NAME PLATE - REAR BACKUP LIGHT RELAY |
1 |
|
|
|
|
? |
58B-06-50480 |
NAME PLATE - KEY CONTROL POWER RELAY |
1 |
|
|
|
|
? |
58B-06-50530 |
NAME PLATE - LOW MOUNTING HEADLIGHT RELAY |
1 |
|
|
|
|
? |
58B-06-50520 |
NAME PLATE - HIGH MOUNTING HEADLIGHT RELAY |
1 |
|
|
|
|
? |
58B-06-50510 |
NAME PLATE - HIGH BEAM HEADLIGHT RELAY |
1 |
|
|
|
|
? |
58B-06-50490 |
NAME PLATE - LADDER DECK LIGHT RELAY |
1 |
|
|
|
|
? |
58B-06-50380 |
NAME PLATE - PMT |
1 |
|
|
|
|
? |
MM0352 |
MACHINE SCREW - M5 X 0.8 X 25 |
6 |
|
|
|
|
? |
58E-06-00060 |
BRACKET |
1 |
|
|
|
|
? |
MM0378 |
LOCKWASHER, EXTERNAL TOOTH - M4 |
4 |
|
|
|
|
? |
MM0344 |
MACHINE SCREW - M4 X 0.7 X 20 |
4 |
|
|
|
|
? |
MM0372 |
NUT - M4 X 0.7 |
4 |
|
|
|
|
? |
58E-06-00420 |
DUCT, WIRING |
1 |
|
|
|
|
? |
58B-06-30090 |
HARNESS, WIRING - AHT PLUG2 |
1 |
|
|
|
|
? |
XC2803 |
CONNECTOR |
1 |
|
|
|
