Корень Dump Trucks Komatsu AFE NEW AFE78-AY 930E-5 S/N A40170 THEISS(afe78-ay)
CRANKING MOTOR WIRING 1/2(100 : 65162)
















Item PartNo Description Qty Options Ref Alt
? CH4517 CABLE, BLACK 1
? 58D-90-00700 CLAMP, CUSHIONED - 7/16" 6
? WB3097 CLAMP, CUSHIONED - 1/2" 7
? WB1303 CLAMP, CUSHIONED - 3/4" 5
? EJ3891 CLAMP ASSEMBLY 10
? 426-06-11570 BRACKET 3
? 58F-46-40190 BRACKET 1
? EM3364 ROD, THREADED 10
? EM1278 ROD, THREADED - M6 X 1.00 X 105 5
? MM0713 FLAT WASHER, HARDENED - M10 5
? MM0469 LOCKWASHER - M6 14
? MM0176 NUT - M6 X 1.00 14
? MM0604 CAPSCREW - M10 X 1.50 X 20 5
? MM0471 LOCKWASHER - M10 5
? MM0178 NUT - M10 X 1.50 4
? MM0461 FLAT WASHER - M10 2
