Корень Dump Trucks Komatsu AFE NEW AFE78-AY 930E-5 S/N A40170 THEISS(afe78-ay)
ISOLATION BOX EXTERNAL WIRING 2/2(094 : 65205)















Item PartNo Description Qty Options Ref Alt
? 58F-06-10580 CABLE, RED 1
? 58F-06-10480 CABLE, RED 1
? 58F-06-10860 CABLE, BLACK 1
? 58F-06-10530 CABLE, BLACK 1
? 58F-06-10760 CABLE, BLACK 1
? MM0606 CAPSCREW - M10 X 1.50 X 30 6
? MM0461 FLAT WASHER - M10 12
? MM0471 LOCKWASHER - M10 6
? MM0178 NUT - M10 X 1.50 6
? MM0594 CAPSCREW - M8 X 1.25 X 25 9
? MM0470 LOCKWASHER - M8 8
? MM0460 FLAT WASHER - M8 8
? NOTE: NS = NOT SHOWN
? XB6860 SLEEVE, SHRINK 2
? XB5737 SLEEVE, SHRINK 2
