Корень Dump Trucks Komatsu AFE NEW AFE78-AY 930E-5 S/N A40170 THEISS(afe78-ay)
LUBE PUMP ASSEMBLY 3/3 58F-98-40240(928 : 43903)
































Item PartNo Description Qty Options Ref Alt
? BF5470 SCREW, FLAT HEAD 2
? 58F-98-40380 WEIGHT, COUNTER 2
? BF5473 RING, RETAINING 2
? BF5511 RING, RETAINING 2
? BF5475 CRANK, ECCENTRIC 1
? BF5476 BEARING, BALL 1
? BF5474 CRANKROD 1
? 58F-90-00050 SCREW, PIVOT 2
? 58F-90-00130 BUSHING, PIN 2
? BF5477 PIN, OUTLET 1
? O-RING (1) 1
? 58F-90-00140 ANCHOR, WRIST PIN 1
? O-RING (1) 1
? WASHER, BACKUP (1) 1
? SEAL, CUP (1) 1
? BF5478 UPPER BUSHING AND PLUNGER 1
? RING, STEEL BACKUP (1) 1
? O-RING (1) 1
? CLIP, RETAINER (1) 1
? 58F-98-40630 ROD, PLUNGER 1
? SPRING (1) 1
? 58F-98-40610 ROD, CHECK 1
? BALL, STEEL (1) 1
? 58F-90-00150 PLUNGER, PUMP 1
? 58F-98-40680 TUBE, RECIPROCATING 1
? SEAL, CUP (1) 1
? O-RING (1) 2
? 58F-90-00160 CAGE, BALL 1
? BALL, STEEL (1) 1
? BF5488 SEAT, CHECK 1
? 58F-98-40740 NOTE: (1) NOT SERVICED SEPARATELY. INCLUDED IN
? 58F-98-40740 SEAL KIT.
