Item |
PartNo |
Description |
Qty |
Options |
Ref |
Alt |
|
? |
EJ6749 |
PISTON AND HOUSING ASSEMBLY |
1 |
|
|
|
|
? |
EJ6748 |
• HOUSING, PISTON |
1 |
|
|
|
|
? |
58F-33-40000 |
• SEAL (2) |
1 |
|
|
|
|
? |
58F-33-40010 |
• SEAL (2) |
1 |
|
|
|
|
? |
EG4953 |
• PISTON |
1 |
|
|
|
|
? |
PB8864 |
• SPRING |
12 |
|
|
|
|
? |
ED3327 |
• GUIDE, SPRING |
12 |
|
|
|
|
? |
VL1222 |
• CAPSCREW - 1/2" - 13NC X 5" |
12 |
|
|
|
|
? |
VM0315 |
PLUG (2)/(3) |
3 |
|
|
|
|
? |
WA1589 |
CAPSCREW, 12 PT - 7/8" - 9NC X 3" |
102 |
|
|
|
|
? |
WA5659 |
FLAT WASHER, HARDENED |
102 |
|
|
|
|
? |
VM0317 |
PLUG (2)/(3) |
1 |
|
|
|
|
? |
ED3339 |
GEAR, RING |
1 |
|
|
|
|
? |
EH7197 |
O-RING (2) |
2 |
|
|
|
|
? |
ED3343 |
GEAR, INNER |
1 |
|
|
|
|
? |
EM8367 |
DAMPER (1) |
2 |
|
|
|
|
? |
EM8365 |
DISC, SEPARATOR (1) |
9 |
|
|
|
|
? |
EM8366 |
DISC, FRICTION (1) |
10 |
|
|
|
|
? |
58F-32-40040 |
PLATE, BACK |
1 |
|
|
|
|
? |
PC0651 |
SEAL ASSEMBLY (2) |
1 |
|
|
|
|
? |
PC1431 |
SEAL, OIL (2) |
1 |
|
|
|
|
? |
58F-32-40030 |
CARRIER, SEAL |
1 |
|
|
|
|
? |
EH7195 |
O-RING (2) |
1 |
|
|
|
|
? |
58F-32-40050 |
BRACKET, MOUNTING |
1 |
|
|
|
|
? |
VN9065 |
CAPSCREW - 1/2" - 13NC X 2" |
12 |
|
|
|
|
? |
58B-09-50080 |
FLAT WASHER, HARDENED - 1 1/4" |
32 |
|
|
|
|
? |
ED3755 |
SHIM - .020" |
54 |
|
|
|
|
? |
ED3756 |
SHIM - .010" |
6 |
|
|
|
|
? |
WA5660 |
CAPSCREW, 12 PT - 1 1/4" - 12NF X 7 1/2" |
32 |
|
|
|
|
? |
58F-32-40051 |
BRACKET, MOUNTING (3) |
6 |
|
|
|
|
? |
D2930 |
CAPSCREW, SOCKET HEAD - 1/2" - 13NC X 3/4" (3) |
6 |
|
|
|
|
? |
C1612 |
CAPSCREW - 1/2" - 13NC X 1" (3) |
12 |
|
|
|
|
? |
WA0360 |
FLAT WASHER, HARDENED - 1/2" (3) |
24 |
|
|
|
|
? |
58F-BK-AK100 |
NOTE: (1) INCLUDED IN 58F-BK-AK100 BRAKE DISC KIT. |
|
|
|
|
|
? |
58F-BK-AK290 |
(2) INCLUDED IN 58F-BK-AK290 REAR BRAKE SEAL KIT. |
|
|
|
|
|
? |
|
(3) USED FOR ASSEMBLY AND STORAGE ONLY. |
|
|
|
|
|
? |
|
REMOVE WHEN INSTALLED ON THE TRUCK. |
|
|
|
|
