Корень Dump Trucks Komatsu AFE NEW AFE78-AY 930E-5 S/N A40170 THEISS(afe78-ay)
FUEL SYSTEM PIPING 1/4(054 : 68035)





















Item PartNo Description Qty Options Ref Alt
? WB0274 FITTING, ELBOW - 90 DEG 1
? SD5210 BUSHING 1
? WB0276 FITTING, ELBOW - 90 DEG 1
? SP4885 BUSHING, PIPE 1
? VN9999 CLAMP, TUBE - 1 1/4" 5
? MM0178 NUT - M10 X 1.50 9
? MM0471 LOCKWASHER - M10 9
? MM0461 FLAT WASHER - M10 9
? XB6667 TUBE 1
? WB0474 FITTING, STRAIGHT 2
? HA8409 HOSE 1
? PB9283 VALVE, SHUTOFF 1
? 58F-04-40010 HOSE 1
? WA4710 CLAMP, HYDRA ZORB - 1 1/2" 9
? WA2566 FITTING, CAP NUT 1
? 58E-04-00810 TUBE 1
? WB0451 FITTING, TEE 1
? 58E-04-00651 VENT 1
? PB5556 FILTER, SPIN-ON 1
? WB3098 CLAMP, CUSHIONED - 3/8" 1
? EK9883 SPACER 1
