Корень Dump Trucks Komatsu AFE NEW AFE78-AY 930E-5 S/N A40170 THEISS(afe78-ay)
AUXILIARY HYDRAULIC SYSTEM 1/2(536 : 69095)





















Item PartNo Description Qty Options Ref Alt
? WB0593 FITTING, STRAIGHT 1
? 58F-60-40970 HOSE 1
? MM0605 CAPSCREW - M10 X 1.50 X 25 5
? WB3092 CLAMP, CUSHIONED - 7/8" 12
? MM0461 FLAT WASHER - M10
? MM0471 LOCKWASHER - M10
? EM1393 SPACER 3
? 58F-60-40981 HOSE 1
? WB0821 FITTING, STRAIGHT 1
? WB1308 CLAMP, CUSHIONED - 1 1/16" 10
? 426-06-11570 BRACKET 2
? EM4587 ROD, THREADED 2
? EM1398 SPACER 2
? WB3095 CLAMP, CUSHIONED - 2 1/4" 1
? MM0178 NUT - M10 X 1.50 16
? 58E-06-30610 SWITCH, PRESSURE 1
? 58F-60-10700 FITTING, ELBOW 1
? PC2208 FITTING 1
? WB1302 CLAMP, CUSHIONED - 5/16" 14
? EL7273 SPACER 4
? WB1306 CLAMP, CUSHIONED - 2" 1

Dump Trucks Komatsu / AFE NEW / AFE78-AY 930E-5 S/N A40170 THEISS(afe78-ay) / AUXILIARY HYDRAULIC SYSTEM 1/2(536 : 69095)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
