Item |
PartNo |
Description |
Qty |
Options |
Ref |
Alt |
|
? |
|
HOUSING (1) |
1 |
|
|
|
|
? |
58B-98-01210 |
PISTON |
1 |
|
|
|
|
? |
EC1015 |
GAS VALVE ASSEMBLY |
1 |
|
|
|
|
? |
TD7179 |
• CORE, VALVE |
1 |
|
|
|
|
? |
EC1447 |
• BODY, VALVE |
1 |
|
|
|
|
? |
TL3995 |
• O-RING (2) |
1 |
|
|
|
|
? |
58B-98-01271 |
GUARD, GAS VALVE |
1 |
|
|
|
|
? |
XA5153 |
GAS VALVE ASSEMBLY |
1 |
|
|
|
|
? |
58B-98-01280 |
RING, BACKUP (2) |
2 |
|
|
|
|
? |
58B-98-01200 |
SEAL, PISTON - "T" (2) |
1 |
|
|
|
|
? |
58B-60-20140 |
SEAL (2) |
2 |
|
|
|
|
? |
58B-60-20150 |
O-RING (2) |
2 |
|
|
|
|
? |
58B-98-01350 |
PLUG, O-RING (2)/(3) |
2 |
|
|
|
|
? |
58B-98-01290 |
CAPSCREW, SOCKET HEAD - 3/8" - 16NC |
2 |
|
|
|
|
? |
58B-98-01250 |
HEAD, GAS END |
1 |
|
|
|
|
? |
58B-98-01360 |
PLATE, ASME |
1 |
|
|
|
|
? |
58B-98-01370 |
PLATE, AS1210 |
1 |
|
|
|
|
? |
58F-98-50100 |
NAME PLATE |
3 |
|
|
|
|
? |
58B-98-01260 |
HEAD, OIL END |
1 |
|
|
|
|
? |
58B-98-01190 |
SEAL, PISTON - "U" (2) |
2 |
|
|
|
|
? |
58B-98-01310 |
RING, BACKUP (2) |
2 |
|
|
|
|
? |
58B-98-01300 |
BEARING, PISTON (2) |
2 |
|
|
|
|
? |
|
NOTE: (1) NOT SERVICED SEPARATELY. |
|
|
|
|
|
? |
58B-98-01320 |
(2) INCLUDED IN 58B-98-01320 ACCUMULATOR OVERHAUL SEAL KIT. |
|
|
|
|
|
? |
|
(3) FOR STORAGE PURPOSES ONLY. |
|
|
|
|
