Корень Dump Trucks Komatsu AFE NEW AFE78-AY 930E-5 S/N A40170 THEISS(afe78-ay)
HOIST PILOT VALVE ASSEMBLY PB6922(474 : 40064)
































Item PartNo Description Qty Options Ref Alt
? VE3828 SPOOLING SECTION ASSEMBLY 1
? VJ1967 • CAP 1
? VJ1962 • SPACER 1
? VJ1975 • SNAP RING 1
? VJ1972 • BALL 4
? VJ1964 • PIN, DETENT 1
? VJ1960 • SPRING 1
? VE3823 • SPACER 1
? VJ1957 • CAPSCREW 2
? 1130246C1 • POPPET, CHECK VALVE 1
? VE3826 • SPRING 1
? VE3819 • O-RING 2
? VE3818 • O-RING 2
? VJ1947 • WIPER 2
? BF3536 • SPOOL 1
? VJ0012 • MACHINE SCREW 2
? VJ1943 • PLATE, SEAL 2
? BF3535 • HOUSING, SPOOL 1
? VJ1944 • SEAT, SPRING 2
? 890613C1 • SPRING 1
? VJ1974 • BALL 1
? VE3825 • SLEEVE, DETENT 1
? VE3827 HOUSING, INLET 1
? VE3819 • O-RING 1
? VE3829 HOUSING, OUTLET 1
? VE3821 TIE ROD 2
? VJ1934 NUT 4
? VE3822 TIE ROD 1
? VJ1933 NUT 2
? NOTE: NS = NOT SHOWN
? VE3830 PLUG, SHUT-OFF 1
? VE3980 VALVE, RELIEF 1
