Корень Dump Trucks Komatsu AFE NEW AFE78-AY 930E-5 S/N A40170 THEISS(afe78-ay)
RADIATOR PIPING 4/4(044 : 65157)






















Item PartNo Description Qty Options Ref Alt
? EH3376 TUBE 1
? 58F-03-00400 TUBE 1
? C5772 PLUG, PIPE - 1" 2
? EM8166 TUBE 1
? ED0020 HOSE 1
? WB1051 CLAMP, T-BOLT 3
? EL0043 TUBE 1
? C5771 PLUG, PIPE - 1/2" 2
? EL0044 TUBE 1
? TF6957 DRAIN COCK 2
? E2579 NIPPLE 2
? EF2781 GASKET 2
? WA0839 CAPSCREW, 12 PT - 5/8" - 11NC X 1 1/2" 8
? TR9082 FLAT WASHER - 5/8" 16
? VC1390 LOCKWASHER - 5/8" 12
? EH6686 PLATE, ORIFICE 1
? EF3305 GASKET 2
? 58B-09-00510 CAPSCREW - 5/8" - 11NC X 2 1/4" 4
? TV1749 NUT - 5/8" - 11NC 4
? TA1432 CLAMP ASSEMBLY 1
? EH3383 BRACKET 1
? EH3380 BRACKET 1
