Корень Dump Trucks Komatsu AFE NEW AFE78-AY 930E-5 S/N A40170 THEISS(afe78-ay)
BRAKE VALVE PIPING 1/2(446 : 69226)


















Item PartNo Description Qty Options Ref Alt
? WB0427 FITTING, STRAIGHT 1
? WB0584 FITTING, STRAIGHT 4
? WB0593 FITTING, STRAIGHT 1
? WB0574 FITTING, STRAIGHT 1
? 58E-60-10254 HOSE 3
? 58E-60-20263 HOSE 1
? 58E-60-10284 HOSE 1
? 58C-04-00160 HOSE 1
? TY8375 SPACER 8
? MM0461 FLAT WASHER - M10 16
? MM0178 NUT - M10 X 1.50 8
? WB3092 CLAMP, CUSHIONED - 7/8" 16
? WB1308 CLAMP, CUSHIONED - 1 1/16" 4
? WB1300 CLAMP, CUSHIONED - 5/8" 4
? 58E-54-27260 BRACKET 1
? WB0430 FITTING, STRAIGHT 4
? WB0432 FITTING, STRAIGHT 1
? MM0605 CAPSCREW - M10 X 1.50 X 25 2
