Корень Dump Trucks Komatsu AFE NEW AFE78-AY 930E-5 S/N A40170 THEISS(afe78-ay)
BRAKE COOLING PIPING - RIGHT FRONT 2/2(432 : 65230)









Item PartNo Description Qty Options Ref Alt
? TF8090 CLAMP, SPLIT FLANGE - 1 1/2" 4
? C1614 CAPSCREW - 1/2" - 13NC X 1 1/2" 8
? C1540 LOCKWASHER - 1/2" 8
? WB0537 FITTING, ELBOW - 45 DEG 1
? WA2567 FITTING, CAP NUT 1
? WB1057 REDUCER 1
? PB6769 COUPLING, MALE 1
? TL3995 • O-RING 1
? 162144 • CAP, DUST 1
