Title	Page	Reference
RELIEF VALVE ASSEMBLY 58B-98-01650	394	61152
SPOOL SECTION ASSEMBLY VE3810	396	65333
SPOOL SECTION ASSEMBLY - TANK BF3050	398	65335

Item	PartNo	Description	Qty	Ref
?	BF3045	TIE ROD	4
?	VE3807	WASHER, COMPRESSION	8
?	VE3804	LOCKNUT	8
?	58B-98-50200	INLET SECTION ASSEMBLY	2
?	VJ2002	• CAPSCREW	8
?	VJ1987	• CAPSCREW	8
?	58B-98-50100	• PLUG	1
?	VE3557	• SCREW, RESTRICTION	1
?	VE3551	• PLUG	5
?	VE3565	• O-RING (2)/(3)	7
?	VE3563	• CAP, FLANGE	1
?	VE3553	• O-RING (2)	1
?	VE3559	• FITTING (1)	1
?	VE3564	• TUBE	1
?	VE3561	• FITTING	1
?	VE3803	• CAPSCREW	2
?	VE3560	• SLEEVE	1
?	VE3554	• RING, BACKUP (3)	2
?	VE3552	• O-RING (3)	1
?	1133800C1	• RING, BACKUP (3)	2
?	VE3526	• O-RING (3)	1
?	BF3254	• POPPET, RESTRICTION	1
?	VE3562	• COVER	1
?	58F-60-40400	• SPRING	1
?	58F-60-40410	• SPRING	1
?	VJ1989	• SLEEVE	1
?	VE3609	• RELIEF VALVE ASSEMBLY (2)	1
?	VE3533	• O-RING (2)/(3)	4
?	BF3046	• HOUSING, INLET	1
?	VJ1988	• POPPET	2
?	VJ1985	• SPRING	2
?	VE3568	• COVER, POPPET	1
?	VE3534	• O-RING (2)	2
?	VE3528	• O-RING (2)/(3)	4
?	58B-98-01650	• RELIEF VALVE ASSEMBLY (2)/(4) (SEE INDEX)	1	61152
?	VJ1990	• SPRING	1
?	VE3810	SPOOL SECTION ASSEMBLY (SEE INDEX)	1	65333
?	VE3806	PLATE, SPACER	1
?	BF3050	SPOOL SECTION ASSEMBLY (SEE INDEX)	1	65335
?		NOTE: (1) NOT SERVICED SEPARATELY.
?	58B-98-01660	(2) INCLUDED IN 58B-98-01660 MAJOR SERVICE KIT.
?	BF3048	(3) INCLUDED IN BF3048 MINOR SERVICE KIT.
?	58B-98-50000	(4) INCLUDED IN 58B-98-50000 RELIEF VALVE KIT.

?
