Корень Dump Trucks Komatsu AFE NEW AFE78-AY 930E-5 S/N A40170 THEISS(afe78-ay)
GRID BLOWER MOTOR 4/4 58F-98-01340(314 : 68214)







Item PartNo Description Qty Options Ref Alt
? XA4288 SENSOR, SPEED 1
? 58F-98-02200 SENSOR BRACKET ASSEMBLY 1
? VE4258 MOUNT, RUBBER 4
? VE4696 LOCKWASHER - 5/16" 21
? VE4626 NUT - 5/16" - 18NC 3
? 58E-00-01570 FLAT WASHER - 5/16" 3
? (SEE FOLLOWING PAGES FOR SECTION VIEWS.)
