Корень Dump Trucks Komatsu AFE NEW AFE78-AY 930E-5 S/N A40170 THEISS(afe78-ay)
CONTROL CABINET 11/13(274 : 64967)
























Item PartNo Description Qty Options Ref Alt
? 58B-43-01200 RESISTOR BOARD 2
? 58F-43-00870 SPACER 8
? 58F-43-01430 WASHER - 1 3/7" 32
? 58F-43-01630 CAPACITOR, DC POWER 7
? 58F-43-00860 GASKET 14
? VE4601 LOCKWASHER - #10 14
? VE4655 FLAT WASHER - #10 14
? VE4902 NUT - 1/4" - 20NC 8
? XA5003 LOCKWASHER - 1/4" 8
? VE4515 FLAT WASHER - 3/8" 4
? VE4700 NUT - 3/8" - 16NC 4
? VE4687 LOCKWASHER - 3/8" 4
? 58F-43-01420 INSULATION 4
? VE4602 NUT - #10 - 32NF 18
? GE0177 BOARD, PRINTED WIRE 4
? 58B-43-00250 WASHER - 1/2" OD 16
? PB3606 SPACER 16
? XA3130 ADAPTER 4
? XA3129 CAP, LENS 2
? NOTE: NS = NOT SHOWN
? 58F-43-01860 HARNESS, WIRING - LV2 1
? 58F-43-01870 HARNESS, WIRING - CMH 1
? 58F-43-01960 HARNESS, WIRING - LV3 1
? 58F-43-01970 HARNESS, WIRING - CGH 7

Dump Trucks Komatsu / AFE NEW / AFE78-AY 930E-5 S/N A40170 THEISS(afe78-ay) / CONTROL CABINET 11/13(274 : 64967)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
