Item	PartNo	Description	Qty
?	58E-06-18254	PLATE	1
?	MM0040	CAPSCREW - M6 X 1.00 X 35	4
?	58F-06-50380	NUT, KNURLED - M8 X 1.25	8
?	58E-06-18480	COVER, WIRE	2
?	58E-06-18390	DUCT, WIRE	2
?	58E-06-10360	SCREW, FLANGE - #10 - 24NC X 3/4"	8
?	58E-06-10350	NUT, RIBBED - #10 - 24NC	8
?	58E-06-40520	NAME PLATE - CAN	1
?	WB4010	NAME PLATE - CAN RPC	2
?	WB4009	NAME PLATE - CAN J1939	1
?	58E-06-11160	PLATE, INTERFACE	2
?	58E-06-40530	NAME PLATE - PLM 4	1
?	58E-06-40511	NAME PLATE	1
?	58E-06-11360	TAG, PLATE - GB21	1
?	58E-06-11350	TAG, PLATE - GB20	1
?	EK2723	NAME PLATE - INTERFACE MODULE	1
?	EJ9089	CONTROLLER, INTERFACE MODULE	1
?	MM0460	FLAT WASHER - M8	8
?	MM0470	LOCKWASHER - M8	8
?	MM0401	CAPSCREW - M8 X 1.25 X 90	4
?	08193-21012	CLIP	8
?	58E-06-40310	SCREW, FLANGE - M10 X 1.50 X 20	8
?	MM0471	LOCKWASHER - M10	17
?	58E-06-40300	NUT, RIBBED - M10 X 1.50	8
?	58E-06-00060	BRACKET	1
?	MM0459	FLAT WASHER - M6	6
?	MM0581	CAPSCREW - M6 X 1.00 X 16	2
?	58B-06-10010	CONTROLLER, PAYLOAD METER 4	1
?	58E-06-08150	PLATE	1
?	58E-06-20350	CAPSCREW - M8 X 1.25 X 110	4
?	58B-06-10400	COMMUNICATION INTERFACE, PAYLOAD METER 4	1
?	MM0469	LOCKWASHER - M6	4
