Корень Dump Trucks Komatsu AFE NEW AFE78-AP 930E-5 S/N A40105 - A40106 THEISS(afe78-ap)
ISOLATION BOX EXTERNAL WIRING 2/2(092 : 68107)











Item PartNo Description Qty Options Ref Alt
? 58F-06-10580 CABLE, RED 1
? 58F-06-10480 CABLE, RED 1
? 58F-06-10860 CABLE, BLACK 1
? 58F-06-10530 CABLE, BLACK 1
? 58F-06-10760 CABLE, BLACK 1
? MM0606 CAPSCREW - M10 X 1.50 X 30 9
? MM0461 FLAT WASHER - M10 15
? MM0471 LOCKWASHER - M10 9
? MM0178 NUT - M10 X 1.50 6
? NOTE: NS = NOT SHOWN
? XB6860 SLEEVE, SHRINK (76 X 150 MM) 4
