Корень Dump Trucks Komatsu AFE NEW AFE78-AP 930E-5 S/N A40105 - A40106 THEISS(afe78-ap)
ISOLATION BOX 2/3(086 : 68105)


























Item PartNo Description Qty Options Ref Alt
? 58E-06-01880 PLATE 1
? MM0594 CAPSCREW - M8 X 1.25 X 25 6
? MM0470 LOCKWASHER - M8 6
? MM0460 FLAT WASHER - M8 6
? MM0343 MACHINE SCREW - M4 X 0.7 X 16 4
? MM0378 LOCKWASHER, EXTERNAL TOOTH - M4 8
? MM0372 NUT - M4 X 0.7 4
? PB6842 HOOK, RUBBER 1
? C1639 CAPSCREW - 5/16" - 18NC X 2" 1
? VN9951 LOCKNUT - 5/16" - 18NC 1
? 58E-06-02091 RELAY BOX ASSEMBLY 1
? 58E-06-01311 HARNESS, WIRING - ISOLATION BOX INTERNAL 1
? PC2528 SWITCH, LOCKOUT 1
? TC1231 LOCKWASHER - 3/8" 2
? MM0461 FLAT WASHER - M10 2
? DC3101 LOCKWASHER - #10 5
? HD8390 FLAT WASHER, COPPER - # 10 2
? VN7121 MACHINE SCREW - # 10 - 24NC X 1/2" 3
? VC5344 FLAT WASHER - #10 3
? 58E-06-01890 BUS BAR 1
? 58E-06-10200 BUS BAR 1
? 58E-06-10100 BUS BAR 1
? 58E-06-10420 BUS BAR 1
? DF3500 LOCKNUT - 1/2" - 13NC 4
? MM0578 CAPSCREW - M6 X 1.00 X 10 4
? SD4235 LOCKWASHER, EXTERNAL TOOTH - 1/4" 4
