Item |
PartNo |
Description |
Qty |
Options |
Ref |
Alt |
|
? |
EH7195 |
O-RING (1) |
1 |
|
|
|
|
? |
EJ7475 |
GEAR, SPEED SENSOR |
1 |
|
|
|
|
? |
58F-32-00201 |
SPINDLE |
1 |
|
|
|
|
? |
PC3059 |
BEARING ASSEMBLY, INNER (1) |
1 |
|
|
|
|
? |
562-22-32290 |
PIN (1) |
2 |
|
|
|
|
? |
ED3772 |
SPACER, BEARING |
1 |
|
|
|
|
? |
EH7194 |
O-RING (1) |
1 |
|
|
|
|
? |
EH7196 |
O-RING (1) |
1 |
|
|
|
|
? |
ED3775 |
ADAPTER, BRAKE |
1 |
|
|
|
|
? |
58F-32-00193 |
FRONT BRAKE ASSEMBLY (SEE INDEX) |
1 |
|
62918 |
|
|
? |
569-33-81241 |
ADAPTER |
1 |
|
|
|
|
? |
58C-32-00451 |
TANK, CATCHMENT |
1 |
|
|
|
|
? |
07002-52034 |
O-RING (1) |
1 |
|
|
|
|
? |
58F-33-00400 |
SEAL ASSEMBLY (2) |
1 |
|
|
|
|
? |
PC1431 |
SEAL, OIL (1) |
1 |
|
|
|
|
? |
58F-33-00181 |
CARRIER, SEAL |
1 |
|
|
|
|
? |
58F-32-50001 |
BRACKET, MOUNTING |
6 |
|
|
|
|
? |
58F-32-00151 |
CARRIER, FLOATING SEAL |
1 |
|
|
|
|
? |
58F-32-00170 |
SEAL ASSEMBLY (1) |
1 |
|
|
|
|
? |
58F-32-00161 |
CARRIER, FLOATING SEAL |
1 |
|
|
|
|
? |
H8402 |
PLUG - 3/8" |
1 |
|
|
|
|
? |
58F-22-00850 |
VENT, BREATHER (1) |
2 |
|
|
|
|
? |
58F-32-00180 |
O-RING (1) |
1 |
|
|
|
|
? |
07000-52018 |
O-RING (1) |
1 |
|
|
|
|
? |
EH7193 |
O-RING (1)/(2) |
1 |
|
|
|
|
? |
D2930 |
CAPSCREW, SOCKET HEAD - 1/2" - 13NC X 3/4" |
6 |
|
|
|
|
? |
C1612 |
CAPSCREW - 1/2" - 13NC X 1" |
12 |
|
|
|
|
? |
C1613 |
CAPSCREW - 1/2" - 13NC X 1 1/4" |
4 |
|
|
|
|
? |
DF6928 |
CAPSCREW - 1/2" - 13NC X 1 3/4" |
16 |
|
|
|
|
? |
WA0360 |
FLAT WASHER, HARDENED - 1/2" |
24 |
|
|
|
|
? |
WA5669 |
CAPSCREW, 12 PT - 1 1/4" - 12NF X 3 1/2" |
57 |
|
|
|
|
? |
WA5660 |
CAPSCREW, 12 PT - 1 1/4" - 12NF X 7 1/2" |
32 |
|
|
|
|
? |
TY2149 |
FLAT WASHER, HARDENED - 1 1/4" |
89 |
|
|
|
|
? |
58F-SM-AK060 |
NOTE: (1) INCLUDED IN 58F-SM-AK060 SPINDLE |
|
|
|
|
|
? |
|
MAINTENANCE KIT. BALANCE OF PARTS ON PREVIOUS FIGURE. |
|
|
|
|
|
? |
|
(2) NOT INCLUDED IN ASSEMBLY. |
|
|
|
|
|
? |
|
(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
|
|
|
|
