Корень Dump Trucks Komatsu AFE NEW AFE78-AP 930E-5 S/N A40105 - A40106 THEISS(afe78-ap)
CENTER DECK HEAT SHIELDS(744 : 69684)






















Item PartNo Description Qty Options Ref Alt
? 58F-80-20470 SHIM 8
? 58F-80-20480 SHIM 4
? 58F-80-20461 SHIM 4
? 58F-80-10170 SHIM 4
? 58F-80-20330 SHIM 8
? 58F-80-10260 SHIM 4
? 58F-80-10250 SHIM 4
? 58F-80-10191 SHIM 8
? 58F-80-10140 SHIM 4
? 58F-80-11261 SHIELD, HEAT 1
? 58F-80-20620 SHIELD, HEAT 1
? 58F-80-20720 SHIELD, HEAT 1
? 58F-80-10291 SHIELD, HEAT 1
? 58F-80-10350 BRACKET 2
? 58F-80-10330 SHIELD, HEAT 2
? 58F-80-10390 BRACKET 1
? 58F-80-06410 BRACKET 1
? 58F-80-10310 BRACKET 1
? 58F-80-10371 BRACKET 1
? MM0606 CAPSCREW - M10 X 1.50 X 30 26
? MM0713 FLAT WASHER, HARDENED - M10 26
? MM0471 LOCKWASHER - M10 26
