Корень Dump Trucks Komatsu AFE NEW AFE78-AP 930E-5 S/N A40105 - A40106 THEISS(afe78-ap)
HYDRAULIC TANK MUD FLAPS (STANDARD)(728 : 64755)







Item PartNo Description Qty Options Ref Alt
? XB5485 MUD FLAP 1
? WA4726 FLAT WASHER, HARDENED - 3/8" 11
? TZ3103 RETAINER, FLAT 1
? EM1775 BRACKET 1
? C1603 CAPSCREW - 3/8" - 16NC X 1 1/4" 9
? C1521 NUT - 3/8" - 16NC 5
? C0312 LOCKWASHER - 3/8" 9
