Корень Dump Trucks Komatsu AFE NEW AFE78-AP 930E-5 S/N A40105 - A40106 THEISS(afe78-ap)
BRAKE MANIFOLD PC2513(468 : 68328)













































Item PartNo Description Qty Options Ref Alt
? BF2839 VALVE, NEEDLE 2
? BF2864 • O-RING (1) 1
? BF2860 • O-RING (1) 1
? BF2863 • RING, BACKUP (1) 2
? BF2840 VALVE, CHECK 3
? BF2860 • O-RING (2) 1
? BF2864 • O-RING (2) 1
? BF2865 • RING, BACKUP (2) 1
? XA3347 VALVE, SOLENOID 2
? BF2838 PLUG, CAVITY 1
? XA4154 VALVE, PRESSURE REDUCING 1
? BF2860 • O-RING (4) 1
? BF2866 • O-RING (4) 1
? BF2864 • O-RING (4) 1
? BF2872 • RING, BACKUP (4) 1
? BF2863 • RING, BACKUP (4) 2
? BF2851 DISC, ORIFICE 1
? BF2845 PLUG, CAVITY 1
? BF2850 DISC, ORIFICE 1
? BF2841 VALVE, PILOT (AUTOMATIC APPLY) 1
? BF2860 • O-RING (5) 1
? BF2866 • O-RING (5) 1
? BF2867 • O-RING (5) 1
? BF2864 • O-RING (5) 1
? BF2863 • RING, BACKUP (5) 1
? BF2868 • RING, BACKUP (5) 2
? XA6420 • RING, BACKUP (5) 2
? BF3260 PLUG, PORT 7
? BF2846 CARTRIDGE, LOAD SHUTTLE 1
? BF2860 • O-RING (3) 1
? BF2866 • O-RING (3) 1
? BF2864 • O-RING (3) 1
? BF2863 • RING, BACKUP (3) 1
? BF2868 • RING, BACKUP (3) 2
? BF2847 CARTRIDGE, HOT OIL 1
? BF2860 • O-RING (6) 1
? BF2864 • O-RING (6) 1
? BF2865 • RING, BACKUP (6) 2
? BF3261 PLUG, PORT 2
? BF2853 NOTE: (1) INCLUDED IN BF2853 SEAL KIT.
? BF2854 (2) INCLUDED IN BF2854 SEAL KIT.
? BF2856 (3) INCLUDED IN BF2846 SEAL KIT.
? BF2857 (4) INCLUDED IN BF2857 SEAL KIT.
? BF2855 (5) INCLUDED IN BF2855 SEAL KIT.
? BF2858 (6) INCLUDED IN BF2858 SEAL KIT.

Dump Trucks Komatsu / AFE NEW / AFE78-AP 930E-5 S/N A40105 - A40106 THEISS(afe78-ap) / BRAKE MANIFOLD PC2513(468 : 68328)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
