Корень Dump Trucks Komatsu AFE NEW AFE78-AP 930E-5 S/N A40105 - A40106 THEISS(afe78-ap)
FRONT BRAKE DUAL RELAY VALVE PIPING & INSTALLATION(462 : 69461)

















Item PartNo Description Qty Options Ref Alt
? 58B-60-10401 DUAL RELAY VALVE 1
? SR6320 CAPSCREW - 1/2" - 13NC X 7/8" 2
? DD5640 FLAT WASHER - 1/2" 2
? WB1024 FITTING, STRAIGHT 1
? 58B-60-30631 HOSE 1
? WB0510 FITTING, ELBOW - 90 DEG 1
? 58F-60-51520 HOSE 1
? WB0584 FITTING, STRAIGHT 2
? 58F-60-42260 HOSE 1
? 58F-60-51620 HOSE 1
? WB0585 FITTING, STRAIGHT 1
? WB3855 CLAMP, CUSHIONED - 13/16" 3
? EL3892 SPACER 1
? MM0178 NUT - M10 X 1.50 1
? MM0471 LOCKWASHER - M10 1
? MM0461 FLAT WASHER - M10 1
? VM0314 PLUG 1
