Корень Dump Trucks Komatsu AFE NEW AFE78-AP 930E-5 S/N A40105 - A40106 THEISS(afe78-ap)
HYDRAULIC BRAKE CABINET STRUCTURE 2/2(450 : 65009)











Item PartNo Description Qty Options Ref Alt
? WB0432 FITTING, STRAIGHT 4
? WB0430 FITTING, STRAIGHT 13
? WB0429 FITTING, STRAIGHT 2
? 58F-09-00190 FITTING, TEE 2
? WB0451 FITTING, TEE 1
? H8402 PLUG - 3/8" 2
? HD3680 COUPLING, PIPE 2
? VN9787 FLAT WASHER - 1-1/8" 8
? TF2449 FLAT WASHER - 3/4" 26
? VN9780 FLAT WASHER - 9/16" 6
? 58F-80-44400 PLUG 3
