Корень Dump Trucks Komatsu AFE NEW AFE78-AP 930E-5 S/N A40105 - A40106 THEISS(afe78-ap)
HYDRAULIC BRAKE CABINET INSTALLATION(446 : 69462)
Title Page Reference
HYDRAULIC BRAKE CABINET STRUCTURE 1/2 448 68066








Item PartNo Description Qty Options Ref Alt
? MM0620 CAPSCREW - M12 X 1.75 X 40 4
? MM0472 LOCKWASHER - M12 12
? MM0179 NUT - M12 X 1.75 8
? MM0714 FLAT WASHER, HARDENED - M12 8
? 58E-54-26330 CAP 2
? MM0623 CAPSCREW - M12 X 1.75 X 60 4
? 58B-54-50080 PLATE 1
