Корень Dump Trucks Komatsu AFE NEW AFE78-AP 930E-5 S/N A40105 - A40106 THEISS(afe78-ap)
HIGH TEMPERATURE CORE 58F-03-02100(036 : 68465)



















Item PartNo Description Qty Options Ref Alt
? 58F-03-02300 TANK 1
? 58F-03-02310 TANK, CENTER 1
? 58F-03-02320 TANK 1
? 58F-03-02330 MEMBER, SIDE 1
? 58F-03-02340 MEMBER, SIDE 1
? 58F-03-02350 ROD, TENSION 2
? C1540 LOCKWASHER - 1/2" 28
? VE3460 CAPSCREW, HEAVY DUTY - 1/2" - 13NC X 1" 28
? 58F-03-02370 AIR BAFFLE, TOP 4
? 58F-03-02380 AIR BAFFLE, BOTTOM 4
? VE1285 BRACKET, X-BRACE 2
? 58F-03-02360 ROD, X-BRACE 2
? C1528 NUT - 3/4" - 16NF 12
? XA2806 FLAT WASHER - 5/16" 6
? VE6312 NUT - 5/16" - 18NC 2
? C5747 CAPSCREW - 5/16" - 18NC X 3/4" 4
? XA2721 SEAL, RUBBER 752
? XA2720 SEAL, RUBBER 752
? 58F-03-02390 TUBES 752
