Корень Dump Trucks Komatsu AFE NEW AFE78-AP 930E-5 S/N A40105 - A40106 THEISS(afe78-ap)
CONTROL CABINET 7/7(264 : 45678)
























Item PartNo Description Qty Options Ref Alt
? VE4516 WASHER 3
? 58F-43-01460 COTTER PIN - 1/16" X 1" 3
? 58F-43-01840 BOOT, HOLZ RUBBER 1
? 58F-43-01250 PLATE, MOUNTING 1
? 58F-43-01360 LINING, GLASTIC 1
? 58F-43-01160 LINING, GLASTIC 1
? 58F-43-01260 LINING, GLASTIC 1
? VE4687 LOCKWASHER - 3/8" 1
? VE4515 FLAT WASHER - 3/8" 1
? 58F-43-01650 GROUND STRAP 1
? VE2338 CAPSCREW - 5/16" - 16NC X 3/4" 1
? 58F-43-01060 GASKET 1
? NOTE: NS = NOT SHOWN
? 58F-43-01660 HARNESS, WIRING - GDH 1
? 58F-43-01760 HARNESS, WIRING - LV1 1
? 58F-43-01860 HARNESS, WIRING - LV2 1
? 58F-43-01960 HARNESS, WIRING - LV3 1
? 58F-43-01070 HARNESS, WIRING - LV4 1
? 58F-43-01170 HARNESS, WIRING - LV5 1
? 58F-43-01270 HARNESS, WIRING - HV2 1
? 58F-43-01080 HARNESS, WIRING - SSH 1
? 58F-43-01370 HARNESS, WIRING - JMP 1
? 58F-43-01470 HARNESS, WIRING - FOH 1
? 58F-43-01570 HARNESS, WIRING - CCL 1
