Корень Dump Trucks Komatsu AFE NEW AFE78-AP 930E-5 S/N A40105 - A40106 THEISS(afe78-ap)
CONTROL CABINET EXTERNAL WIRING - WHEEL MOTOR 1/2(240 : 69306)




















Item PartNo Description Qty Options Ref Alt
? WA1578 TAPE, FILLER 3
? 58E-90-10010 PLATE 1
? XB0741 CLAMP, CABLE - 4 HOLE 1
? WB1300 CLAMP, CUSHIONED - 5/8" 10
? WB3093 CLAMP, CUSHIONED - 1" 5
? EL6380 ROD, THREADED 1
? TR4436 FLAT WASHER, HARDENED - 3/8" 10
? 58E-09-10000 ROD, THREADED - 3/8" - 16NC X 2 3/4" 5
? EM4587 ROD, THREADED 12
? VN0137 CLAMP, CUSHIONED - 7/16" 14
? MM0178 NUT - M10 X 1.50 3
? MM0471 LOCKWASHER - M10 7
? MM0461 FLAT WASHER - M10 2
? MM0464 FLAT WASHER - M16 3
? MM0474 LOCKWASHER - M16 3
? EB9886 STUD, THREADED 4
? MM0181 NUT - M16 X 2.00 3
? EM1398 SPACER 16
? TC1233 NUT - 3/8" - 16NC 5
? TC1231 LOCKWASHER - 3/8" 10

Dump Trucks Komatsu / AFE NEW / AFE78-AP 930E-5 S/N A40105 - A40106 THEISS(afe78-ap) / CONTROL CABINET EXTERNAL WIRING - WHEEL MOTOR 1/2(240 : 69306)
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
?
